Product Introduction
Juzheng XR-1200C series digital split-type metal detector can eliminate signal interference furthest from products themselves (like ore, coal, chemical, renewable resources, waste etc.) and conveyor belt itself by using DSP digital intelligent technology, at the same time, ensuring conveyor and products (like ore, coal, chemical, renewable resources, waste etc.) to pass detector, also can achieve good detection results.
Specification
| Model | XR-1200C |
| Material of Construction | Carbon steel with painting (SUS is OPTIONAL) |
| Memory Function | Store 100 product parameters |
| Operation Panel Languages | English, Spanish, Korean, Chinese |
| Auto-learning Function | Yes |
| Aperture Size | Width: 1000-2400mm, Height: 200-1000mm (Can be customized) |
| Screen | 3.2'' LCD with buttons |
| Alarming | Release alarm signal to controller or automatic reject system or stop with alarm |
| Working Temperature | -10℃~40℃ (14℉~104℉) |
| Humidity | Below 90% Relative humidity ( Non-condensing) |
| Power Supply | Alternating current 110-380V (+10%,-15% 50/60Hz) |
Application
It is widely used for plastic, building material, wood, paper making, coal, textile, mines, cement, thermal power, chemical, chemical, waste processing and renewable resources industry etc. It is used for detecting bulk metallic impurities left or mixed with products, which can help avoid damage to working machines.
Main Components
Manufacturing
Our Customers
Certifications
+86 13751397283
