Product Introduction
The XR-10kg-400mm Dynamic Checkweigher is a high-performance inline weighing system designed to accurately detect underweight and overweight products on high-speed production lines. With a weighing range of up to 10kg and a 400mm wide conveyor belt, this model is perfect for medium-to-large sized packages in industries such as food, chemical, logistics, and manufacturing.Engineered with an advanced load cell and fast digital processing, the XR-10kg-400mm ensures precise weight control with minimal false rejects.
The modular reject system supports push rod, air blow, or drop flap options, customizable to your needs.
Specification
| Model | XR-10kg-400mm |
| Belt width(mm) | 400 |
| Weighing range | 10g-10kg |
| Max speed(pcs/min) | 100 |
| Display resolution(g) | 0.1 |
| Operation Panelzhengfu | 10'' Touchable Screen |
| Conveyor height | 800 ± 50mm |
| Language | English / Chinese / Vietnamese / Spanish |
| Conveyor direction | From left to right / From right to left |
| Power | AC220V ± 10%50HZ(60HZ) |
| MS weighing scale module | JZXR-80TL |
| Load cell | ZEMIC/HBM/Mettler Toledo |
| Motor | German JSCC |
| Inverter | German JSCC |
| Conveyor belt | White PU Food-grade belt with FDA certificated |
| Working Environment | 0℃~40℃ |
| Material of construction | SUS 304 |
| Rejection system | Please refer to Automatic Rejection Systems |
| Humidity | 90% Relative humidity (without condensate) |
Application
WHAT ARE OUR SERVICE PROCESS?
Pre-sales Services:
1. Collecting customer’s product information and requirement.
2. Providing solution and offer for customer’s review 12 Hours after information colletion.
3. Hundreds of service cases and videos will help our customer to understand our machine better.
Kindly reminder:
Please provide below information when you send inquiry, so that we can quickily provide the precise feedback and the suitable solution for you.
Product details (Product Name, Min./Max. Dimension & Weight )
Package details (Packaging Material, Dimension, Shape)
Capacity and inspection accuracy requirement
Other special requirements
In-sale service:
4. Sending the machine drawings for customer’s approval before mass production.
5. Following up each production process to make sure on-time delivery.
6. Sending the machine inspection video for customer’s approval before delivery.
7.Working with forwarder for the shipping and keep the customer updated on ETD & ETA.
After-sales service:
8. Manules / Videos of machine installation, adjusting, setting, maintenance are available for our customers.
Online after-sales service:
9. We will give response in 4 hours in case of machine failure, solutions will be offered in 24 hours via whatsapp,wechat and facebook. What’s more, our engineer team can speak English, which can communicate more effective.
